The ultrasonic cell disruptor is an advanced solution designed for efficient and precise cell disruption. This all-in-one device combines all necessary components in a compact design, making it ideal for laboratories with limited space. It offers exceptional control and versatility for various scientific and industrial applications.
Ultrasonic Cell Disruptor Feature:
- Split Design: Enhances flexibility and customization, suitable for a range of experimental needs.
- Longer service life and increased output efficiency of a 3D exponential ultrasonic probe
- Function Modes: On/Off, Pulse, and Timer (from 1 minute to 99 hours)
- 7″ touch screen for intuitive use and observation
- User-Friendly Interface: Easy-to-navigate controls for seamless operation.
- Safety Features: Built-in safety mechanisms to protect both the user and samples.
Ultrasonic Cell Disruptor Specifications:
| Model No. |
UCD-I300 |
UCD-I600 |
UCD-I1200 |
UCD-I1800 |
UCD-I2200 |
UCD-I3000 |
| Frequencies |
19~26KHz |
| Power |
300W |
500W |
1000W |
1500W |
1800W |
2000W |
| Capacity |
0.1~300ml |
0.1~600ml |
0.1~1200ml |
0.1~1800ml |
0.1~2200ml |
0.1~3000ml |
| Optional Probes |
Φ3(0.1~500ml) |
Φ3(0.1~50ml) |
Φ(0.1~50ml) |
Φ10(50~500ml) |
Φ10(50~500ml) |
Φ10(50~500ml) |
| Φ6(50~300ml) |
Φ6(50~500ml) |
Φ(50~400ml) |
Φ16(50~1200ml) |
Φ16(50~1200ml) |
Φ16(50~1200ml) |
| Φ10(200~300ml) |
Φ8(300~500ml) |
Φ8(500~1200ml) |
Φ18(1000~1800ml) |
Φ18(1000~2200ml) |
Φ18(1000~2200ml) Φ20(1000~3000ml) |
| Standard Probe |
Φ3mm |
Φ6mm |
Φ10mm |
Φ16mm |
Φ18mm |
Φ20mm |
| Applications |
EP tube Microsample |
Small Processing Capacity |
Routine Laboratory |
Routine Laboratory |
Large Pprocessing Capacity |
Large Processing Capacity |
Advantages of Ultrasonic Cell Disruptor:
- Ten user groups for processes that can be programmed
- 1%-100% power output variation
- Real-time display with auto-tracking and auto-amplitude correction at 19-26 KHz
- Sample temperature monitoring and auto protection between 0°C and 300°C
- AC 85V-260V operating power is suitable for any laboratory worldwide.
Application of Ultrasonic Cell Disruptor:
- Molecular Biology: Cell lysis, DNA/RNA, and protein extraction.
- Biotechnology: Produces biofuels, pharmaceuticals, and biopharmaceuticals.
- Nanotechnology: Prepares nanoparticles and nanomaterials.
- Environmental Science: Extracts contaminants from soil, water, and air.
- Food & Beverage: Extracts flavors, colors, and nutrients.
- Pharmaceutical Research: Aids in drug formulation and synthesis.
- Clinical Diagnostics: Extracts biomarkers for medical research and testing.
WHY SCITEK
- 24 Months Limited Warranty
- CE & FDA Standards
- 1-2 Days Handling and 7-30 Days Shipping
