The ET-T01 transfer electrophoresis tank enables cooled or uncooled protein or nucleic acid transfers. The optional Heat Exchange Module can be easily integrated into the ET-T01 to transfer up to 2 gels simultaneously. When the optional heat exchange module is not used, up to 4 gels can be transferred at a time.
Transfer Electrophoresis Tank Feature:
- The transfer electrophoresis system is a very user-friendly method of transferring proteins from gel to film in the quickest amount of time. It is the ideal fusion of conventional transfer technology.
- For effective and quick transfer, the transfer electrophoresis tank is equipped with an integrated high-current power source that directly regulates the current flowing between the titanium anode and stainless steel cathode.
- The entire electrophoresis system is made to be easily and quickly operative, enabling researchers to obtain data more quickly.
- 1-4 mini gels or 1-2 bigger gels can be transferred in a single run.
- Excellent compatibility with conventional semi-dry consumables, high transfer efficiency, and adaptability of transfer circumstances.
Transfer Electrophoresis Tank Specifications:
| Model |
ET-T01 |
| Display |
7-inch touch LCD screen display |
| Transfer Plate Size(mm) |
180×145 |
| Programs |
25 running programs that can store custom edits |
| Maximum Output Voltage |
0-25V (1V increment) |
| Large Output Current |
0-2.5A (0.1A increment) |
| Shipping Size(W×D×H)(mm) |
440×380×370 |
| N.W./G.W. (kg) |
4.2/6 |
| Standard Accessories |
| Name |
Quantity |
| Main Body |
1 |
| Transfer Plate |
1 |
| Bubble Rolling |
1 |
Applications of Transfer Electrophoresis Tank:
- Protein Separation: Efficiently transfers proteins from gels to membranes for Western blotting.
- Nucleic Acid Transfer: Facilitates the transfer of DNA or RNA from agarose gels to nylon or nitrocellulose membranes.
- High-Throughput Analysis: Supports multiple samples simultaneously for increased experimental throughput.
- Custom Protocols: Allows storage of up to 25 custom run programs for varied experimental needs.
- Real-Time Monitoring: Provides real-time display of transfer conditions and running status, ensuring precise control.
