This thermostatic shaking water bath is widely used for bacterial culture, fermentation, hybridisation, biochemical reactions as well as enzyme and tissue studies.
Our thermostatic shaking water bath is an excellent laboratory instrument that combines precise temperature control with oscillatory mixing. It is capable of mixing samples perfectly and regulating the temperature accurately. Whether for cell culture, biochemistry or other scientific experiments, this shaking water bath is your right-hand man. Buy it now and enjoy the ease and efficiency of cutting-edge technology.
| Model | SK-WB12 | SK-WB24 | SK-WB48 |
| Control Mode | P. I. D (Microcomputer scans the micro-processing chip) | ||
| Display Mode | LCD (Large liquid crystal screen) | ||
| Oscillation Mode | Repeated | ||
| Drive Mode | Track drive by single shaft | ||
| Ambient Temperature Requirement (℃) | 15-35 | ||
| Curve Programing Settings | Programing settings of repetition, steps and eight-section curves | ||
| Safety Functions | Audio and light alarm for temperatures above or below the upper or lower limit; Alarm for speeds above or below the upper or lower limit; Sensor fault identification, stand-alone over-temperature protector, Stand-alone leakage or over-current protection and refrigerator overload protection. | ||
| Additional Functions | Speed storage, automatic stop, temperature and speed correction, monitoring timer, clock display, startup after power again, parameter memory, parameter encryption, one-touch factory reset | ||
| Temperature Control Range (℃) | Room temperature -100 | ||
| Accuracy of Temperature (℃) | ±1 (0.At constant temperature) |
||
| Temperature Uniformity (℃) | ±0.2 | ||
| Speed Range (r/min) | 20-200 | ||
| Speed Accuracy (r/min) | ±1 | ||
| Amplitude of Rocking Plate (mm) | 25 | ||
| Timing Range (min) | 0-999.59 | ||
| Size of Rocking Plate/mm | 430×320 | 590×390 | 780×586 |
| Number of Rocking Plates | 1 | ||
| Max Capacity | 250ml×12 or 500ml×8 or 1000ml×6 | 250ml×24 or 500ml×15 or 1000ml×8 | 250ml×48 or 500ml×30 or 1000ml×20 |
| Capacity (L) | 46 | 82 | 170 |
| Power (W) | 2200 | 2200 | 4000 |
| Power Supply | AC 200~240V 50∽60Hz | ||
| Material of Chamber | 316 stainless steel (With strong acid and alkali resistance and better corrosion resistance) | ||
| Material of Outer Box | High-quality nodular cast iron, channel steel, angle steel, medium plates and cold rolled steel sheets | ||
| Chamber Size (mm) | 510×380×240 | 700×455×260 | 940×660×275 |
| Sizes (W×D×H)(mm) | 760×420×370 | 945×495×408 | 1240×700×760 |
| Shipping Size (W×D×H)(mm) | 910×650×550 | 1100×710×570 | 1370×850×1020 |
| N.W./G.W. (kg) | 56/65 | 68/120 | 133/180 |
Thermostatic shaking baths excel at thawing, heating, mixing and shaking samples. Its constant shaking action is particularly beneficial for microbiological applications, ensuring that liquid cell cultures are kept in constant motion. The thermostatic shaking bath allow them to constantly interact with air. This water bath is carefully designed to provide precise temperature control as well as seamless reciprocal horizontal shaking.
What is the principle of thermostatic water bath?
The operation of a water bath is based on a simple yet effective principle: a sensor detects the temperature of the water, converting it into a resistance value. This value is then amplified and analyzed by an integrated amplifier, which in turn generates a control signal. This signal is utilized to regulate the average heating power of the electric heating tube, ensuring that the water remains at a constant temperature. This process efficiently maintains the desired temperature for various applications.
Difference between thermostatic water bath and water bath?
Generally speaking, the water bath is a simple heating device, which is suitable for relatively simple temperature requirements, while the constant temperature bath is a precise constant temperature device, which is suitable for experiments and industrial applications that require high temperature control.
