Fluorescence Microscope Feature:

The viewing head’s integrated 10-inch display improves the user experience by doing away with the need for conventional eyepieces and offering a practical and engrossing visual platform.
The C Mount 0.5×/1x video adapter for Fluorescencemicroscope enables smooth connectivity with imaging equipment.
With achromatic objectives (4x, 10x, 20x, 40x, and 100x), the microscope can be used for a wide range of specimen studies while maintaining excellent optical performance at different magnifications.
For precise sample manipulation, the double mechanical stage offers stability and flexibility.
Energy-efficient LED lighting provides long-lasting performance and fosters a cozy, well-lit viewing atmosphere.
With its limited-distance optical system, digital integration, precision optics, and adaptability, this fluorescent microscope is ideal for a wide range of uses, such as clinical, educational, and research.

Fluorescence Microscope Specification:

Model	MSC-F201B
Optical System	Infinite Optical System
Viewing Head	Seidentopf binocular head, inclined at 30°, interpupillary 55-75mm
Eyepiece	WF10×20mm
Objective	Infinite plan achromatic objective: 4×, 10×, 40×, 100×
	Flour semi-apo objective: 4x, 10x, 20x, 40x, 100x
	Infinite plan phase objective: Ph10x, 20x, 40x, 100x
Nosepiece	Quadruple nosepiece
Stage	Double layers mechanical stage 140x135mm/ 75x50mm
Condense	Abbe condenser N.A. 1.25 with Iris diaphragm & filter
Focusing System	Coaxial coarse and fine adjustment, fine division 0.002mm, coarse stroke 37.7mm per rotation, fine stroke 0.2mm per rotation, moving range 22mm
Illumination	LED illumination, brightness adjustable
Illumination	5W fluorescent LED illumination, with adjustable brightness
Fluorescent Attachment	DF-I fluorescent vertical illuminator. Equipped with a set of fluorescent channels.
	DF-II fluorescent vertical illuminator equipped with two sets of fluorescence channels
	DF-VI fluorescent vertical illuminator can be configured with three to six groups of fluorescent channels
Shipping Size(W×D×H)(mm)	370x260x470
G.W. (kg)	8
