Benchtop Total Organic Carbon Analyzer

This total organic carbon analyzer is suitable for monitoring wastewater/sewage discharge, cleaning systems, boiler water, cooling water, groundwater and more.

  • Detection Range : 0.001-1.5mg/l
  • Method : Off-line; On-line
  • Detection Limit : 1ppb
  • Max Tolerance : ±5%
  • Sizes (W×D×H)(mm) : 440x220x300; 440x220x405

Share the product

Category:

Benchtop Total Organic Carbon Analyzer Feature:

  1. The total organic carbon analyzer is equipped with a conductivity detector to quantify TOC concentration.
  2. The TOC A1700 supports both online and offline real-time monitoring.
  3. It is the top choice for measuring and monitoring pure water, microelectronic water, and water for injection.
  4. The automatic sample injection design ensures operator safety and prevents sample contamination.
  5. A UV lamp is used for UV oxidation, eliminating the need for adding acid, gas, or a catalyst.
  6. The 7-inch touch screen makes operation easy and intuitive.
  7. An auto sampler is optional to accommodate different experimental requirements.
  8. It includes 8GB of bulk storage.
  9. Each analysis is rapid, taking no more than 3 minutes.
  10. Users can trace back all historical records by searching the test date.
  11. Data can be retrieved directly and saved to a USB interface.
  12. The total organic carbon analyzer is equipped with a Bluetooth printer for quick and easy data printing.

Total Organic Carbon Analyzer Specification:

Model TOC-A1500 TOC-A1700
Detection Range 0.001-1.5mg/l
Method Off-line On-line
Detection Limit 1ppb
Max Tolerance ±5%
Analysis Time 3 min
Response Time Within 10 min
Sample Temperature 1-95°C
Environment Temperature 10-40°C with temperature change ±5℃/d
Sample Flow Speed 1 ml/min
Relative Humidity 0.985
Repeatability Tolerance ≤3%
Drifting ±5%
Power Supply AC 220V, 50/60Hz; 110V, 50/60Hz
Power 100W
Size(W×D×H)(mm) 440x220x300 440x220x405
Shipping Size (W×D×H)(mm) 640x490x440 650x500x450
N.W./G.W. (kg) 11/18 13/20

Applications of Total Organic Carbon Analyzer:

  1. Wastewater Treatment
    Measuring total organic carbon (TOC) emissions at the end of wastewater treatment for plant discharges helps ensure compliance.
  2. Drinking Water Treatment
    The amount of organic matter in drinking water affects, among other things, its appearance and taste. So to ensure drinking water quality, drinking water plants need to measure TOC in both raw and treated water sources.
  3. Dairy Industry
    Monitoring milk fats leaving the plant can increase revenues by reducing product loss and wastewater treatment costs.
  4. Industrial Boilers
    In boilers, the TOC of heat exchanger condensate must be monitored to prevent equipment damage, production downtime and other problems.

WHY SCITEK

  1. 24 Months Limited Warranty
  2. CE & FDA Standards
  3. 1-2 Days Handling and 7-30 Days Shipping
